FEATURES:
Two Mounting Methods. Removable floor stand and wall mount
PRODUCT FEATURES
| Product Model | VOLTA STAGE 1 |
|---|---|
| Nominal Energy | 5.12KWH |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Cell Type | LFP |
| Standard Charge Voltage | 56V |
| Max Discharge Current | 100A |
| Discharge Cut-Off Voltage | 44.8V |
| Parallel Function | Auto-dial CAN |
| Communication Interface | RS485, USB, CAN |
| Change Temperature Range | 0-55°C |
| Dimensions | 480*600*150mm |
| Net Weight | 52Kg |
| Installation Method | Wall Mounted/Floor Standing |
| Warranty | 10 Years (under warranty terms) |
| Energy Throughput | 11MWh |
| Optional | WiFi Remote Monitoring |
