| INPUT (PV DC) |
|
| Max. PV array power (W) |
6000 (3000/3000) |
8000 (4000/4000) |
| Rated PV input voltage (V) |
320 |
| Number of independent MPPT inputs |
2(1:1) |
| PV input voltage range (V) |
100-500 |
| MPPT voltage range (V) |
120-385 |
| Start-up voltage (V) |
100 |
| Max. PV input current per MPPT (A) |
17/17 |
25/25 |
| Max. PV short-circuit current input per MPPT (A) |
25/25 |
32/32 |
| Battery |
|
| Compatible battery type |
Lithium-ion/Lead-Acid |
| Rated battery voltage (V) |
48 |
| Battery voltage range (V) |
38.4-60 |
| Max. charge/discharge current (A) |
70/70 |
90/90 |
110/110 |
140/140 |
| Max. charge/discharge power (W) |
3000 |
4000 |
5000 |
6000 |
| Recommended capacity of battery per inverter |
>100AH |
>200AH |
>200AH |
>200AH |
| Force wake up battery from PV function |
YES |
| Force wake up battery from Grid function |
YES |
| Grid |
|
| Rated AC voltage (V) |
230 |
| Rated AC frequency (Hz) |
50/60 |
| Rated AC input/output current (A) |
13.5 |
17.5 |
22 |
26.5 |
| Rated AC input/output power (W) |
3000 |
4000 |
5000 |
6000 |
| Max. AC input power (W) |
9000 |
| PF |
0.99 (Adjustable from 0.8 leading to 0.8 lagging) |
| THDI |
<5% |
| Max. continuous AC passthrough current (A) |
35 |
40 |
40 |
40 |
| AC Output |
|
| Rated output power (W) |
3000 |
4000 |
5000 |
6000 |
| Rated output voltage (V) |
230 |
| Rated output current (A) |
13.5 |
17.5 |
22 |
26.5 |
| Rated output frequency (Hz) |
50/60 |
| Surge power duration |
2Pn, 5s |
| Switching time |
<15ms@Single/ <30ms@Parallel |
| Wave form |
Sine wave |
| THDV |
<3% |
| Efficiency |
|
| Max. MPPT efficiency |
99.9% |
| Max. charge efficiency |
93.0% |
| Max. discharge efficiency |
93.0% |
| Load MPPT efficiency |
93.0% |
| Protection |
|
| Over current/voltage protection |
YES |
| AC short-circuit current protection |
YES |
| Grid monitoring |
YES |
| DC switch |
YES |
| DC / AC surge protection Type III |
YES |
| Battery reverse polarity protection |
YES |
| General |
|
| Dimensions (W×H×D mm) |
330×505×135mm/13.9×19.9×5.3inch |
| Weight (kg) |
14.5kg |
| Ingress protection rating |
IP20 |
| Operating environment temperature range (℃) |
0~50 |
| Storage temperature range (℃) |
-15~60 |
| Relative humidity |
5%~95% |
| Display & communication interface |
LCD+LED, RS485/Wi-Fi/CAN |
| Warranty |
2 years |
| Cooling method |
Smart cooling |
| Topology |
Transformer-less |
| Altitude |
<2000m |
| Noise emission (typical) |
<50dB |
| Standards & Certification |
|
